XTAR VC4 USB Li-Ion Ni-MH LCD 18350 CR123A 18650 Battery Charger DescriptionXTAR VC4 USB Li-Ion Ni-MH Battery LCD Charger
XTAR VC4 is not only the upgraded version of both VC2 and XP4c chargers, but also the combination of our principle to keep making progress and taking the responsibility for the safety and environment protection. The VC4 can recognize/ display/ charge Ni-MH and Li-ion batteries at the same time and it also displays the charging current, battery voltage and charging capacity. The LCD backlight can be off or automatically into low light mode in 2min to save more energy.
Compatible with different kinds and sizes of most batteries.
3.6v/3.7v Li-Ion / IMR / INR / ICR:
10440 14500 14650 16340
17335 17500 17670
18350 18490 18500 18650 18700
22650 25500 26650
Ni-MH / Ni-CD:
AAAA AAA AA A SC C D
Innovative Tachometerstyle Display.
Screen display information from top to bottom:
Charging Current
Battery Voltage
Battery Capacity
Battery types and Channels
Knows how full your batteries are.
Each interval of battery voltage display is about 10% of your battery capacity.
Batteries are 100% full at 4.2V
Specification:
Lithium Batteries Charging Parameter:
Input: DC 5V 2.1A
Constant Current: 0.5A
Constant Current: 1.0A
Cut-Off Voltage: 4.2 +/- 0.05V
Operation Temperature: 0-40C
Ni-MH Batteries Charging Parameter:
Input: DC 5V 2.1A
Constant Current: 0.5A
Constant Current: 1.0A
Cut-Off Voltage: 1.4 +/- 0.1V
Operation Temperature: 0-40C
USB Output Parameter:
USB Output no-load Voltage: 5.0V
Max Output Current: 1000mA
Battery Over-discharge protection Voltage: 3.0 +/- 0.2v
Contents:
1x VC4 Charger
1x USB Cable
1x Storage Bag
1x Warranty Card
1x Manual
