Power Meter Plug Energy Monitor with Backlight LCD Display
This power energy meter can measure and display voltage, current, energy, frequency, power factor, maximum current & power, time days cost and total kWh. 7 modes for your choice.
The power energy consumption monitor will alarm automatically to warn the user when exceeding the rated power 3680W. The power plug will simultaneously cut off to prevent from damaging.
The blue backlight can be turned on/off manually. Press any button to wake up the backlight. Backlight time: 10 minutes.
UK Plug Power Meter
Power Meter Plug Energy Monitor with Backlight LCD Display Electricity DescriptionPower Meter Plug Energy Monitor with Backlight LCD Display Electricity Usage Monitor Consumption Analyzer Voltage Amps Wattage KWH Outlet Power Meter Socket, Updated Version 360° Viewing Angle
Multiple Measurement Functions: This power energy meter can measure and display voltage, current, energy, frequency, power factor, maximum current & power, time days cost and total kWh. 7 modes for your choice.
Overload Alarm Function: The power energy consumption monitor will alarm automatically to warn the user when exceeding the rated power 3680W. The power plug will simultaneously cut off to prevent from damaging.
Better Visual Experience: UPDATED VERSION with large and clear LCD display, 360° viewing without dead angle, with backlight function, it is clearly visible whatever day or night. The blue backlight can be turned on/off manually. Press any button to wake up the backlight. Backlight time: 10 minutes.
Automatic Data Storage Function: The last data is stored automatically when the power supply abruptly lose. Don't worry about data loss due to a sudden power outage.
Main Features:
1. Electrical parameter measurement function (voltage, current, energy, frequency, power factor, maximum current & power, time days cost and total kWh).
2. Overload warning function (over power alarm threshold 3680W, backlight and power booming noise to alarm).
3. BACKLIGHT function (can be turned off manually).
Backlight time: 10 minutes
4. 360° VIEWING ANGLE, easy to read data clearly.
5. The energy can be reset.
6. Memory function (store data when power off).
7. Large-screen LCD (screen dimension: 45mm x 70mm).
7 Different Display Modes:
Mode 1: Time/Watt/Cost Display
Mode 2: Time/Cumulative Electrical Quantity Display
Mode 3: Time/Voltage/Frequency Display
Mode 4: Time/Current/Power Factor Display
Mode 5: Time/Minimum Power Display
Mode 6: Time/Maximal Power Display
Mode 7: Time/Price Display
Specifications:
3-pin UK plug
Operating voltage: 230VAC
Frequency display: 50Hz
Operating current: max 13A
Wide voltage range: 200V-250V
Wattage display(Watts): 0W-2900W
Current display(Amps): 0.0A---13.0A
Price display range: 0.00 £/kWh---99.99 £/kWh
Total kWh and cost display: 0.000 kWh---9999 kWh, 0.00 £---9999 £
Displays volts, amps and watts accurate: 3%
Package Included:
1 x Power Monitor (UK Plug, updated version)
1 x User Manual
Notes:
You can switch to Mode 7 by pressing the button “COST”.
Press any button to wake up the backlight after it automatically turn off (Backlight time: 10 minutes)
If there is an abnormal display or no response, please reset the electricity power plug by pressing the RESET button.
