This Multi tester can be used for AC/DC voltage test, DC/AC current test, electric current resistance, (DC amplification) test, Frequency test, two-electrode valve test,NPN PNP transistor test, etc.

 Digital LCD multi-meter, can be used for Ohm AC/DC volt test and overhaul all kinds of circuit boards Auto polarity display/Diode test/Transistor P-N junction test/Transistor HFE test

 3 ½ Inch Display

 Blue LCD Back light, 1999 counts, updates 2-3/sec

 Auto Turn off &Data hold function

 Low battery voltage indication

 Continuity test with buzzer sound in circuit

 Overload protection on all ranges.

 You can use the Multi meter in more places, such as factory, school lab, home hobby, machine repairing, etc.

 Specifications:

 Measuring method:Dual-slope integration A/D Converter

 Operating Environment:0 to 40 °C

 Power: 9V Battery (Not Included)

 Fuse Protection: 200mA/250V

 Size: 138mm x 69mm x31mm

 Weight: Approx. 280g

 Measurement Range 200VmV-600V ±0.5% of rdg ± 2 digits

 Overload Protection: 250V rms

 AC Voltage:

 Measurement Range 200V-600V ±1.2% ± 10digits

Overload Protection: 600 VDC or rms

 DC Current:

 Measurement Range DC 2000-10A

±1% of rdg ± 2 digits

Overload Protection: F 200mA / 250V fuse(10A range unfused)

 Resistance:

 Measurement Range 200 Ohms - 2M Ohms ±0.8%of rdg ± 3 digits

Maximum Open Circuit Voltage: 3.2V

Overload Protection: 250V DC or rms

Transistor: Measurement Range hFE T

 Package Contents:

 Digital Multi Meter Voltmeter AC DC Current

With Testing Leads
