Summary
Installation size: 178x50x168mm/7.01x1.97x6.61'
t has a retractable screen which needs to be pulled out manually. Compared with automatic screen, it is more flexible, convenient and durable
When using navigation function, you need to first locate, search for satellite, import maps for normal use.
As long as the car stereo's installation size and machine size match, it can be installed and used.
When installing the machine, be sure to connect the wire correctly. If the installation does not power on the machine, please connect the red wire and yellow wire to the 12V power supply positive pole, the black wire to the power supply negative pole, try to see if the machine can normally power on. If it can be powered on normally, then it may be due to the problem of wiring, you can ask for our help, so that you can use the product better.
7'' 1 DIN Car Radio Stereo MP5 Player EU/UK Map GPS Sat NAV DescriptionVoltage: 12V
Type: car stereo
OS: Win-CE
Software solution: C200S
Screen size: 7 inches standard definition
Screen resolution: 800*480
Panel size: 188mm*58mm/7.40*2.28'
Mobile Interconnection: support
GPS navigation: support
Radio band: FM
Language: English/Chinese/Spanish/Portuguese/Russian/Italian/German/French/Turkish/Czech/Arabic/Hebrew
Power: 60W
Operating temperature: -10~60 ℃
Reversing image: support (camera NOT included)
Brake warning function: support
Steering wheel control: support
bluetooth model: CAR BT
Power amplifier chip: TDA7388
Video output: support
Dual screen simultaneous display: not supported
Built-in offline map: support TF map card (included)
Map type: Europe
WiFi: not supported
Reset button: yes
Button: physical buttons
RCA terminal: 2 channels audio output, 1 channel reverse input, 1 channel video input, 2 channels video output
Front AUX audio input: yes
DVR function: not supported
DAB function: not supported
OBD functionality: not supported
TV function: not supported
DVD movement model: no
4G/ 3G: no
Car logo replacement: not supported
Supported audio format: MP3/WMA/WAV/APE/FLAC
Supported video format: RM/RMVB/AVI/MP4/MKV/3GP (within 720P)
Supported image format: JPG
Notes:
1. There may be slight size deviations due to manual measurement, different measuring methods and tools.
2. The picture may not reflect the actual color of the item because of different photographing light, angle and display monitor.
Package included:
1 X Car Stereo
1 X Tail Line
1 X Remote Control
1 X GPS Antenna
1 X Map Card
2 X Disassemble Tools
1 X Manual
